How it works:

The suspension from the feed tube into the spiral cavity, and close to the bottom of the cone spray spout into the drum through the screw head, the slurry liquid is separated by setting the centrifugal force field in turn wall screen out solid particles were trapped in the basket; at the same time, the solid particles inside the drum under centrifugal force and the differential between the helix and the drum from the drum to the drum small end of the big end of the movement, in this movement, due to the increased diameter of the rotation, the centrifugal force rapidly increasing, high moisture content of the solid phase from the initial entry of the solid phase when a low moisture content to achieve a solid phase discharge drum, in order to achieve solid-liquid phase automatic, continuous separation.

LWL horizontal spiral centrifuge discharge filter is a low energy consumption, stable performance, good separation model. Widely used in chemical, food, salt, mining, pharmaceutical and other industries (for dozens of materials separation, we have successfully applied experience in the selection can communicate with our technical staff in order to obtain more detailed information) . Separation process feed, dehydration, washing and discharging complete a continuous process,

High efficiency and automation of production, is an advanced separation equipment.

Because the separation principle and structural characteristics, the targeting of the material is also strong, for material analysis and selection of appropriate test should be to determine its application and separation performance. Also available for field trials, to avoid the adverse effects caused by the wrong selection.

Main features:

1, drum, spiral and other major parts are corrosion resistant stainless steel, titanium and other materials manufacturing, drum cone angle of 10 ° and 20 °

2, the front end of a specially designed cone bowl inverted cone ring, so that the drum filtration and sedimentation achieve double dehydration

3, continuous feeding, separating, washing, dewatering and solids discharge, high degree of automation, greatly improve labor productivity.

4, customized filter mesh metal plate thickness up to 1.5mm, longer life.

5, better processing capacity, washing effect

6, frequency control, drum speed stepless

7, screw differential speed adjustable

8, simple and reliable independent lubrication station, lubrication, cooling effect

9, security: Configurable speed detection, vibration protection, motor overload protection and spiral differential protection.
