The suspension from the feed tube into the drum, the solid particles in the centrifugal force field by accelerating the settlement of centrifugal force to the drum wall, settled particles driven by screw conveyor blade from (straight section) through the settlement area (Cone section) drying zone to the solid phase outlet; the clarified liquid overflow from the overflow hole. In order to achieve solid, liquid automatic, continuous separation. It can be applied to dehydration, concentration, classification clarification on different occasions.

Main purpose:

The separation of industrial and domestic sewage dewatering

Starch washing, grading, dehydration

Dehydrated soy, wheat protein

Fish meal, fish dehydration

Lees dehydration

Purification and dehydration of fruit juice pulp fibers

Dynamic, vegetable oil separation and purification

Isolation and purification of coal tar

Kaolin, graphite classification and dewatering

Dyes, pigments classification and dewatering

Grade ore slurry dewatering

Main features:

1, drum, spiral and other major parts are made of stainless steel or titanium alloy.

2, the screw conveyor can be sprayed or inserts welded carbide wear-resistant alloy sheet.

3, drum speed stepless.

4, adjustable screw differential speed, there is level or variable speed.

5, simple and reliable lubrication.

6, security: speed detection, vibration protection, motor thermal overload protection, zero differential speed protection.

7, for high viscosity materials, use hydraulic differential, stable and reliable.
